Power Supply for a Compact Server or Homelab in 2026: SFX, SFX-L or ATX, and How Many Watts

Choosing the power supply for a compact server, DIY NAS or homelab: SFX, SFX-L or ATX form factor, how much wattage you need, what 80 PLUS does and does not guarantee, semi-passive fans, ATX 3.1, and the Corsair, be quiet!, Seasonic and EVGA models that come up most often.

S By Selfhostr · no sponsored content
Power Supply for a Compact Server or Homelab in 2026: SFX, SFX-L or ATX, and How Many Watts
This article may contain affiliate links (no extra cost to you, it funds the site). As an Amazon Associate, Selfhostr earns from qualifying purchases. See the disclosure.

👍 What we like

  • 80 PLUS Platinum on the Corsair SF450 and SF750, Gold on the be quiet! Pure Power 12 M and SFX L Power 600W and on the Seasonic Focus SGX-650.
  • 120 mm fan on both SFX-L units (original version for the Seasonic) and on the be quiet! ATX.
  • Fan stopped at low load on the Seasonic Focus SGX-650 and on the Corsair SF450 Platinum (Zero RPM mode).
  • Fully modular cabling on the Corsair SF750, the be quiet! SFX L Power 600W and the Seasonic Focus SGX-650.

👎 What to watch

  • SFX-L units are longer than SFX and do not fit every case designed for SFX.
  • The be quiet! Pure Power 12 M 550W is an ATX unit: it will not fit a case that only accepts SFX.
  • The Seasonic Focus SGX-650's form factor and fan change with the revision (2021: 92 mm).
  • The 92 mm fans on the Corsair SF units have less room than a 120 mm fan to stay slow under heavy load.
📑 Contents ▾

For a home server or DIY NAS without a graphics card, a 450 to 650 W power supply already leaves plenty of headroom. The first criterion is the form factor your case accepts (SFX, SFX-L or ATX). Noise and low-load behaviour come next, well before maximum output. A graphics card changes the calculation: it then sets the wattage, and the ATX 3.1 standard becomes a real criterion.

The specifications of the five power supplies in this selection come from these models’ spec sheets; those of the high-wattage ATX models are the values generally listed: check the exact model. All of them can change from one revision or market to another: the model sold is what counts.

How many watts you need

The method is the same for a server and a PC. Add up the official maximum power draw of the processor, of any graphics card and of each drive, allowing for the spin-up peak of hard drives, then keep a reasonable margin. For a machine that already exists, the most reliable approach is to measure its draw at the wall: see our guide to measuring your homelab’s power consumption.

Oversizing has a hidden cost. 80 PLUS certification measures efficiency at a few specific load levels (20%, 50% and 100% for the Gold level) and says nothing about what happens below 20%. A 650 W unit delivering 40 W is at only about 6% of its capacity. If your machine stays under 100 to 150 W, a higher rated output does not lower the bill: it is only headroom.

A few reference points:

  • ITX NAS or low-power mini server, no GPU: 450 W (Corsair SF450 Platinum) suits a low or mid-range configuration.
  • Busier server or a stack of drives: the 550 to 650 W of the be quiet! Pure Power 12 M, the be quiet! SFX L Power 600W or the Seasonic Focus SGX-650 leave plenty of headroom.
  • Compact case with a power-hungry graphics card: do the maths with the card’s official power draw. The Corsair SF750 (750 W) is the most powerful compact unit on this page.
  • Gaming PC or high-end workstation: a high-end graphics card can draw several hundred watts on its own, and 850 W is often recommended. See the section on ATX power supplies below.

Headroom for a planned upgrade, such as a graphics card you intend to add, saves you buying a second power supply. Buying more “just in case” brings nothing.

SFX, SFX-L or ATX: start from the case

  • ATX: the standard form factor for towers and many mATX NAS cases. It is the easiest to find and to replace.
  • SFX: the compact unit for mini-ITX cases and tight DIY NAS builds, often with a 92 mm fan.
  • SFX-L: an elongated SFX that houses a 120 mm fan. At the same noise level, that fan can spin more slowly. The trade-off is that the unit does not fit every case designed for SFX.

The case spec sheet gives the accepted form factor and often a maximum length. Compare it with the power supply’s official dimensions, without forgetting the room taken by modular cables plugged in at the back. The other way round, an SFX unit can go into an ATX case with an SFX-to-ATX bracket: be quiet! includes one with the SFX L Power 600W, but not every SFX unit has one in the box. To choose the case itself, see our comparison of DIY NAS cases, and for the motherboard that goes with it, which ITX motherboard for a DIY NAS.

ModelForm factor and stated dimensionsContinuous output80 PLUSFanCabling and connectors
Corsair SF450 PlatinumSFX450 WPlatinum92 mm, Rifle Bearing, stopped at low load (Zero RPM)individually sleeved cables; ATX12V v2.4, EPS12V v2.92
Corsair SF750SFX, 100 × 63 × 125 mm750 WPlatinum, up to 92%92 mm, Rifle Bearingfully modular; ATX12V v2.4, EPS 2.92
be quiet! SFX L Power 600WSFX-L (SFX12V 3.3), 130 × 125 × 64 mm600 W (650 W peak)Gold, up to 92%120 mm, sleeve bearing, 1450 rpm maximumfully modular; 4 PCIe 6+2 connectors; SFX-to-ATX bracket included
Seasonic Focus SGX-650SFX-L, 125 × 63.5 × 125 mm (original version) or SFX (2021 revision)650 WGold120 mm (original version), 92 mm (2021 revision); stopped up to about 30% loadfully modular
be quiet! Pure Power 12 M 550WATX 3.0, 160 × 150 × 86 mm550 W (600 W peak)Gold, up to 92.8%120 mmmodular; 12VHPWR connector

Values taken from these models’ spec sheets. They can vary from one revision or market to another.

Efficiency and noise: what 80 PLUS says, and what it does not

Gold or Platinum. An 80 PLUS Platinum unit reaches at least 92% efficiency at 50% load (115 V threshold). That gain mostly plays out between 20 and 100% load, while a home server often spends its time below that. A well-sized Gold unit is therefore a good compromise. Platinum mainly pays off on a machine that genuinely works under load.

The label does not measure noise. A Gold unit can be loud, and a Bronze unit can be quiet. Noise depends on the fan and how it is regulated. A 120 mm fan (ATX or SFX-L) generally has more room than a 92 mm one to stay slow.

Semi-passive mode. Some power supplies keep the fan stopped while load and temperature stay low. The Seasonic Focus SGX-650’s hybrid control has three modes (fanless, silent, cooling): the fan stays off up to about 30% load, then speeds up gradually rather than jumping to full speed. The Corsair SF450 Platinum also has a Zero RPM mode at low load. This behaviour is designed for an always-on machine, since the fan starts as soon as load or temperature requires it. What matters most is that the case gets rid of heat properly, because a power supply running without its fan relies on the surrounding air.

The five power supplies in this selection and what they suit

Corsair SF450 Platinum: the low-power ITX NAS

Corsair lists 450 W continuous in the SFX form factor, 80 PLUS Platinum certification, a 92 mm Rifle Bearing fan and individually sleeved cables. It follows the ATX12V v2.4 and EPS12V v2.92 standards. It is the lowest output in this selection and, with the SF750, one of the two compact units certified Platinum, which makes it the logical candidate for an ITX NAS or a mini server without a graphics card that spends its days at low load with the fan stopped.

Corsair SF750: the power reserve in SFX

With 750 W continuous, the SF750 is the only compact unit on this page above 650 W. Corsair lists 80 PLUS Platinum certification with 92% peak efficiency, fully modular cabling, an SFX form factor of 100 × 63 × 125 mm and OVP, UVP, SCP, OTP and OPP protections (over-voltage, under-voltage, short circuit, over-temperature, over-power). The spec sheet also gives a 50 °C rated temperature, a 100,000-hour MTBF, multi-GPU compatibility and support for Intel C6/C7 sleep states. It is the pick when a power-hungry graphics card has to fit in an SFX case. Its fan is still a 92 mm one: in a small, heavily loaded volume, the case’s airflow matters as much as the power supply.

be quiet! SFX L Power 600W: the quiet SFX-L

It targets mini-ITX cases that accept SFX-L. be quiet! lists 600 W continuous, 650 W peak, the SFX12V 3.3 standard, an active PFC + LLC + DC/DC topology and 80 PLUS Gold certification with up to 92% efficiency. The 120 mm fan, with a sleeve bearing and a 4-pole motor, tops out at 1450 rpm. Cabling is fully modular, with four PCIe 6+2 connectors, and the spec sheet lists protection against over-temperature, over-current, short circuits, over-voltage and under-voltage. It is a good candidate for a compact DIY NAS where quiet matters. The included SFX-to-ATX bracket also lets you fit it in a tower.

Seasonic Focus SGX-650: semi-passive mode

It is the most powerful SFX-L unit in this selection (650 W), with 80 PLUS Gold certification and fully modular cabling. Its strength for a homelab is the hybrid fan control described above, which keeps the fan off up to about 30% load. Watch the version: the original Focus SGX is a 125 × 63.5 × 125 mm SFX-L unit with a 120 mm fan, while Seasonic describes a 2021 revision that is 100 mm wide with a 92 mm fan. The form factor therefore depends on the version sold: check the exact model and its dimensions before ordering.

be quiet! Pure Power 12 M 550W: the ATX option

This is not an SFX power supply: it is a 160 × 150 × 86 mm ATX unit, for a tower homelab, an mATX server or a NAS case that accepts ATX. be quiet! lists 550 W continuous on two independent 12 V rails, 600 W peak, 80 PLUS Gold certification with up to 92.8% efficiency, an LLC + SR + DC/DC topology, a 120 mm fan and modular cabling. It follows the ATX 3.0 standard and has a 12VHPWR connector, which leaves the door open to a recent graphics card. For a server built around an efficient processor, 550 W leaves comfortable headroom.

With a graphics card: ATX, 850 W and up, ATX 3.1

Once a graphics card goes into the machine, for gaming, local AI or transcoding, it drives the choice. The ATX 3.1 standard sets new requirements for handling graphics card power spikes and for the 12V-2x6 connector. A recent unit labelled ATX 3.0 or ATX 3.1 has a 12VHPWR or 12V-2x6 connector for recent cards. For a server without a GPU, it is not a criterion. Among the spec sheets checked for this page, only the be quiet! Pure Power 12 M 550W’s lists ATX 3.0. For the RM850x, the PRIME TX-1000 or the G6 range, the standard depends on the revision: check for the ATX 3.x label on the model offered.

The ATX units that often come up for a build with a graphics card:

  • Corsair RM850x: 850 W, 80 PLUS Gold, fully modular cabling. It is the level often recommended for a high-end build with a single graphics card.
  • Corsair AX850: 850 W, 80 PLUS Titanium, with a fan that only starts from a moderate load. It is listed with classic PCIe 6+2 connectors, without 12VHPWR.
  • Seasonic PRIME TX-1000: 1000 W, 80 PLUS Titanium, fully modular cabling, for a multi-GPU workstation or a very power-hungry processor.
  • EVGA SuperNOVA P2 750 W: 750 W, 80 PLUS Platinum, with classic PCIe 6+2 connectors and no 12VHPWR.
  • Other high-wattage ATX units: Seasonic’s 1000 W models or the EVGA SuperNOVA G6 range, certified 80 PLUS Gold. Output and certification depend on the exact model: read them on the spec sheet of the unit offered.

Titanium or Platinum efficiency does not make a unit ATX 3.1. A power supply whose spec sheet has no 12VHPWR or 12V-2x6 connector will need an adapter with a graphics card that uses that connector. If you are buying for a recent graphics card, look for the ATX 3.1 label and the 12V-2x6 cable on the exact model. To build a local AI machine, see also our guide to building a local AI server with a GPU.

Before you order: compatibility checks

  1. SFX and SFX-L are not interchangeable. SFX-L is longer. Many ITX cases accept it, but not all: the maximum length stated by the case manufacturer is what counts, cables included.
  2. Count the drive connectors. A stack of six or eight drives can need more SATA or Molex connectors than a typical PC: backplane, drives and fans included.
  3. Do not reuse modular cables from another brand. Pinouts are not standardised on the power supply side. A cable from another brand can destroy hardware.
  4. Read the spec sheet of the model you are buying. Standards, topology, protections and bearing type vary from one model to another, and sometimes from one revision to another, as on the Seasonic Focus SGX-650.
  5. Size the UPS on actual consumption. What the machine draws at the wall is what counts, not the rating printed on the power supply: see what UPS capacity for a NAS or homelab.

Key facts

450 to 750 W (SFX and SFX-L)
Compact models' output
Platinum (Corsair SF450, SF750), Gold (be quiet! Pure Power 12 M and SFX L Power 600W, Seasonic Focus SGX-650)
80 PLUS certification
SFX, SFX-L and ATX
Form factors
Seasonic Focus SGX-650: up to about 30% load
Fan stopped
