Best SSD for NAS Cache in 2026: L2ARC, SLOG, NVMe or SATA

Which SSD should you pick for a TrueNAS, Synology, QNAP or Unraid NAS cache in 2026? TBW endurance, DRAM, PLP for SLOG, rated IOPS and the NVMe vs SATA choice, based on manufacturer spec sheets.

S By Selfhostr · no sponsored content
Best SSD for NAS Cache in 2026: L2ARC, SLOG, NVMe or SATA
This article may contain affiliate links (no extra cost to you, it funds the site). As an Amazon Associate, Selfhostr earns from qualifying purchases. See the disclosure.

👍 What we like

  • An NVMe cache absorbs the random reads and write bursts that hard drives handle poorly
  • NAS-oriented SSDs (WD Red SN700, Seagate IronWolf 525) are rated for 1400 to 2000 TBW at 1TB, versus 600 to 800 TBW for the Samsung 990 Pro, Crucial T500 and Kingston KC3000
  • A PCIe 4.0 SSD still works in a PCIe 3.0 M.2 slot

👎 What to watch

  • None of the consumer SSDs in this comparison has PLP: avoid them as a standalone ZFS SLOG without a UPS
  • An NVMe drive in a closed NAS enclosure can heat up to throttling without a heatsink
  • For transfers from a PC over gigabit, the network caps out before the SSD
📑 Contents ▾

For a read-only NAS cache, a consumer PCIe 4.0 NVMe SSD does the job, preferably one with dedicated DRAM such as the Samsung 990 Pro; the Crucial T500 is the cheaper option, and 1TB is enough for most homelabs. As soon as the cache takes writes (Synology read/write cache, Unraid cache pool, VMs), endurance matters more than speed, and NAS-oriented SSDs such as the WD Red SN700 or the Seagate IronWolf 525 are rated for much higher TBW: 1400 to 2000 TBW at 1TB, versus 600 to 800 TBW for the consumer models listed (Samsung 990 Pro, Crucial T500, Kingston KC3000). For a ZFS SLOG, none of these SSDs has power loss protection (PLP): you need an enterprise SSD, or failing that a UPS. The figures on this page come from manufacturer spec sheets; we do not measure these SSDs ourselves.

What is the SSD for: reads, writes, SLOG or cache pool?

The right SSD depends first on what you ask of it. The four common uses do not wear the drive the same way, nor carry the same risk if it fails.

RoleSystemWhat the SSD absorbsTop criterionMirror
Read cache (L2ARC, read-only)TrueNAS, Synology, QNAPfrequent reads, few writeslatency, DRAMunnecessary: losing it costs no data
Read/write cacheSynology, QNAPwrites before they reach the disksendurance (TBW)essential
Cache poolUnraidwrites to the data disks, containers, VMsendurance (TBW)recommended
SLOG (ZIL)TrueNASsynchronous writes (NFS, iSCSI, databases)PLP, latencyrecommended

The SLOG is often misunderstood: on ZFS, it only speeds up synchronous writes. A regular SMB share or snapshots do not need one. If you serve neither NFS, iSCSI nor a demanding database, an L2ARC, or no cache at all, will do more for your performance. Our tutorial on configuring a ZFS cache on your NAS covers setting up both.

The criteria that separate cache SSDs

Endurance (TBW): the figure that matters for writes

TBW (terabytes written) caps the wear covered by the warranty. The WD Red SN700 spec sheet says it plainly: the 5-year warranty ends earlier if the endurance limit is reached. For a read cache, wear stays moderate. A read/write cache, an Unraid pool or a SLOG rewrite constantly: there, the gap between models becomes decisive. At 1TB, the SN700 is rated for 2000 TBW and the IronWolf 525 for 1400 TBW, versus 600 TBW for the Samsung 990 Pro or the Crucial T500. TBW rises with capacity: from 600 to 1200 TBW between 1 and 2TB for the 990 Pro, from 2000 to 2500 TBW for the SN700.

Dedicated DRAM or HMB

A DRAM-less SSD borrows part of the system RAM (HMB) for its mapping table. That is fine on a workstation, but under sustained random load, typically a NAS cache, latency degrades. The Samsung 990 Pro carries LPDDR4 DRAM, while the Samsung 990 EVO Plus relies on HMB according to its spec sheet: for a cache, the former is the better pick of the two.

PLP: the protection consumer SSDs lack

Power loss protection relies on capacitors that give the SSD time to write out what it holds in volatile memory. It is standard on enterprise SSDs and missing from every consumer model on this page. Without it, a power cut can lose the last synchronous writes the system believed were committed. That is secondary for a read cache, critical for a SLOG.

Interface: PCIe 3.0 or 4.0

Most recent NAS units have M.2 slots running at PCIe 3.0 or 4.0. A PCIe 4.0 SSD works in a PCIe 3.0 slot, capped at ~3500 MB/s: no need to pay for top speed if your NAS tops out at PCIe 3.0. For a cache, latency and endurance weigh more than sequential throughput anyway. Also check that your NAS’s M.2 slot accepts the 2280 length, which is that of the Samsung 990 Pro, WD Red SN700, WD Black SN850X and Seagate IronWolf 525 according to their spec sheets: some NAS units do not take that length (2242 is a shorter format) or require a specific mounting screw. Finally, check the manufacturer’s compatibility list, especially with Synology.

Heat

The Samsung 990 Pro and WD Red SN700 spec sheets give an operating temperature of 0 to 70 °C. In a closed NAS enclosure without directed airflow, an NVMe drive can reach 70-80 °C under sustained writes and slow down to protect itself. If your NAS’s M.2 slots have no heatsink, a small passive heatsink is usually enough.

NVMe SSDs for NAS cache compared

ModelInterfaceRated sequential read / writeRated TBWProfile
Samsung 990 ProPCIe 4.0 x47450 / 6900 MB/s600 (1TB), 1200 (2TB)high end, LPDDR4 DRAM
WD Red SN700PCIe 3.0 x43400 / 2900 MB/s (2TB)2000 (1TB), 2500 (2TB)built for 24/7 NAS use
Seagate IronWolf 525PCIe 4.0 x45000 / 4400 MB/s (2TB)1400 (1TB), 2800 (2TB)built for NAS, 5-year warranty
Crucial T500PCIe 4.0 x47400 / 7000 MB/s (2TB)600 (1TB), 1200 (2TB)PCIe 4.0 at a moderate price

None of these four models has PLP. Sequential speeds mostly separate the models on paper: in a NAS, endurance and random-access behaviour are what decide.

Samsung 990 Pro: the reference for a read cache

The Samsung 990 Pro is rated for 7450 MB/s sequential read and 6900 MB/s sequential write over PCIe 4.0, with dedicated LPDDR4 DRAM and a 5-year warranty. It is the natural candidate for an L2ARC or a Synology read cache, and it suits a moderate read/write cache. Its 600 TBW at 1TB, however, stays far from the NAS-oriented models. It heats up under prolonged writes, so plan for a heatsink. For a larger cache, it comes in a 2TB version (1200 TBW).

WD Red SN700: endurance for a cache that writes

The WD Red SN700 is designed for continuous NAS operation. It stays on PCIe 3.0 x4 (3400 MB/s read at 2TB), but its endurance of 2000 TBW at 1TB and 2500 TBW at 2TB puts it ahead of the consumer SSDs in this comparison for a read/write cache, an Unraid pool or write-heavy VMs. WD rates the 2TB model’s MTTF at 1,750,000 hours. The 2TB version is the logical choice for an Unraid pool that receives the day’s downloads or backups.

Seagate IronWolf 525: the other NAS-oriented SSD, on PCIe 4.0

The Seagate IronWolf 525 is a PCIe 4.0 x4 NVMe drive with 3D TLC, backed by a 5-year warranty. It is rated for 5000 MB/s read, less than the 990 Pro, but for 1400 TBW at 1TB and 2800 TBW at 2TB. It is an alternative to the SN700 if your NAS has PCIe 4.0 slots, for a read/write cache or an Unraid pool.

Crucial T500 and Kingston KC3000: the other PCIe 4.0 options

The Crucial T500 is rated for speeds close to the 990 Pro (7400 MB/s read at 2TB) at an often lower price, with the same 600 TBW endurance at 1TB. For a read cache or a homelab where every euro counts, it is the most rational option; check Crucial’s spec sheet, though, to see whether it carries DRAM or relies on HMB, as our sources disagree on this point. The 2TB version goes up to 1200 TBW. The Kingston KC3000 plays in the same category, rated for 800 TBW at 1TB.

Rated IOPS: what the cache changes for VMs and containers

Booting a VM, querying a SQLite database or browsing a photo library index all depend on 4KB random accesses, not sequential throughput. That is where an NVMe SSD crushes hard drives, and it is what the IOPS figures on manufacturer spec sheets measure.

ModelRated random readRated random writeSequential read / write
Samsung 990 Pro1200K to 1400K IOPS depending on capacity1550K IOPS7450 / 6900 MB/s
WD Black SN850X1200K IOPS1100K IOPS7300 / 6600 MB/s

Samsung gives its values at a deep queue depth (QD32); WD does not state the queue depth. The same Samsung spec sheet also gives the figures for one request at a time (QD1): 22K IOPS read and 80K write for the 990 Pro. A VM or a database that waits on each read is closer to that second case. The gain over hard drives remains considerable, but the number on the box is not the one you will see.

The WD Black SN850X is sold with or without a heatsink: the heatsink version helps in a passively cooled NAS, if the M.2 slot has room for it. The Crucial P3 Plus, a QLC drive, sees its performance drop once its SLC cache is exhausted: keep it to a read cache on a small budget, never a write cache.

Keep the network in mind too. For files copied from a PC over gigabit, the link saturates well before the SSD: an NVMe cache mainly speeds up what runs on the NAS itself (Docker containers, VMs, databases, photo indexing).

NVMe or SATA for the cache?

NVMe offers much lower latency and, according to spec sheets, far more random IOPS than a SATA SSD; it runs hotter and draws more power: at 2TB, the Samsung 870 EVO (SATA) is rated at an average of 2.2 W for reads and 2.5 W for writes, versus 4.6 W and 4.2 W active for the Samsung 990 EVO Plus (NVMe). A SATA SSD (6 Gb/s interface) only makes sense for the cache in two cases:

  • Your NAS has no M.2 slot. A 2.5-inch SATA SSD in a drive bay then acts as the cache. The Samsung 870 EVO, for example, carries LPDDR4 DRAM according to its spec sheet. Our comparison of SATA SSDs for NAS and servers lists models suited to 24/7 use.
  • You are building a SLOG. An enterprise SATA SSD with PLP, even a used one (Intel S4510, Samsung PM893), is more reliable as a ZFS log than a fast consumer NVMe drive without PLP.

In every other case, go NVMe.

ZFS SLOG: PLP before speed

A SLOG receives synchronous writes before they are committed to the pool. If it loses its contents in a power cut, that is data the system had already confirmed. Hence three rules:

  1. Pick an SSD with PLP. On the NVMe side, enterprise models such as the Micron 7450 MAX or the Intel D7-P5510 include capacitors; on the SATA side, used Intel S4510 and Samsung PM893 drives do the job.
  2. Mirror the SLOG, so that an SSD failure does not cost the last writes.
  3. Do not share the same SSD between L2ARC and SLOG if you are unsure of your configuration.

If you keep a consumer SSD for lack of a better option, a UPS that triggers a clean NAS shutdown reduces the risk considerably: our tutorial on connecting a UPS to your NAS with NUT shows how.

TrueNAS, Unraid, Synology or QNAP: which SSD for which system

  • TrueNAS (SCALE or Core): for the L2ARC, the Samsung 990 Pro is the strongest candidate among the models listed, provided it is well cooled. For the SLOG, an enterprise SSD with PLP. An oversized L2ARC consumes RAM for its metadata: do not oversize the cache.
  • Unraid: the cache pool receives writes before the data disks (torrents, daily backups, containers). The endurance of the WD Red SN700 or the IronWolf 525 avoids premature wear.
  • Synology and QNAP: compatibility lists are strict. The WD Red SN700 often appears on them, which simplifies enabling the cache in DSM or QTS. DSM may show warnings for an unlisted third-party SSD, and a Samsung 990 Pro may need a firmware update to be recognized or may trigger temperature warnings depending on the NAS model. The step-by-step is in our tutorial on adding an NVMe SSD cache to your NAS.

How much capacity, and how many SSDs?

For a read cache (L2ARC or Synology read-only), 1TB is plenty and remains the best cost/benefit ratio. Go for 2TB when the cache writes a lot, an Unraid pool for example, to benefit from the higher TBW of the larger capacity. For a read/write cache or a SLOG, plan two mirrored SSDs: a non-redundant write cache exposes your data to the failure of a single SSD.

Behind the cache, the choice of hard drives matters just as much: see our comparison of the best NAS hard drives 2026 to build a coherent pool, and the recommended hardware page for M.2 heatsinks.

Key facts

2000 TBW (1TB), 2500 TBW (2TB)
WD Red SN700 endurance
600 TBW (1TB), 1200 TBW (2TB)
Samsung 990 Pro endurance
None
PLP on consumer models
1TB
Recommended cache size

Our picks

Affiliate links · same price for you
Read cache
📦

Samsung 990 Pro

  • PCIe 4.0 x4
  • 600 TBW (1TB), 1200 TBW (2TB)
  • Dedicated LPDDR4 DRAM
View on Amazon

Amazon · price and availability on the listing

Built for NAS
WD Red SN700

WD Red SN700

  • PCIe 3.0 x4
  • 2000 TBW (1TB), 2500 TBW (2TB)
  • Designed for 24/7 NAS use
View on Amazon

Amazon · price and availability on the listing

Cheaper PCIe 4.0
📦

Crucial T500

  • PCIe 4.0 x4
  • 600 TBW (1TB), 1200 TBW (2TB)
  • Up to 7400 MB/s read (2TB)
View on Amazon

Amazon · price and availability on the listing

Heatsink version available
📦

WD Black SN850X 2TB

  • PCIe 4.0
  • 7300 / 6600 MB/s rated
  • 5-year warranty
View on Amazon

Amazon · price and availability on the listing

Tight budget, read-only
📦

Crucial P3 Plus 2TB

  • PCIe 4.0 x4
  • QLC with SLC cache
View on Amazon

Amazon · price and availability on the listing

Designed for NAS
Seagate IronWolf 525 1TB

Seagate IronWolf 525 1TB

  • PCIe 4.0 x4, 3D TLC
  • 1400 TBW (1TB)
  • 5-year warranty
View on Amazon

Amazon · price and availability on the listing
