Best 6-Bay NAS in 2026: Models, Usable Capacity and Expansion for Large Volumes

QNAP TS-673A and TS-664, Synology DS1621+, TerraMaster F6-424, UGREEN DXP6800 Pro: 6-bay NAS units compared from their spec sheets, with usable RAID capacity worked out and the ways to store more (DS923+ with DX517, all-SSD Flashstor 6).

S By Selfhostr · no sponsored content
Best 6-Bay NAS in 2026: Models, Usable Capacity and Expansion for Large Volumes
This article may contain affiliate links (no extra cost to you, it funds the site). As an Amazon Associate, Selfhostr earns from qualifying purchases. See the disclosure.

👍 What we like

  • Six bays: RAID 6 with four drives of usable capacity, or RAID 5 with five.
  • Several models can grow with expansion units (Synology, QNAP, Asustor).
  • M.2 NVMe slots for an SSD cache on the TS-673A, the DS1621+ and the DS923+.

👎 What to watch

  • The DS923+ only has 4 internal bays: you need a DX517 to go beyond 4 drives.
  • The TS-673A's Ryzen V1500B has no video output or hardware transcoding without a PCIe card.
  • Six spinning hard drives make noise and heat: a 6-bay NAS is best kept out of living spaces.
📑 Contents ▾

A 6-bay NAS lets you store a lot without changing enclosures: with six drives, RAID 6 sets aside two drives’ worth of space for parity and leaves four for your data, whereas a 4-bay unit in RAID 6 keeps only two. According to their spec sheets, the QNAP TS-673A is the most expandable of the models whose full spec sheets we recorded (AMD Ryzen V1500B processor, up to 64 GB of RAM, two PCIe slots), the Synology DS1621+ is the 6-bay reference on DSM and the TerraMaster F6-424 is a compact option. If four drives are enough for now, an expandable 4-bay unit such as the Synology DS923+ remains an alternative. The specifications quoted come from spec sheets published by the manufacturers or their resellers, unless stated otherwise: Selfhostr did not measure these NAS units.

Usable capacity: what six bays change

Usable capacity depends on the number of drives, their size and the RAID level. RAID 5 uses the equivalent of one drive for parity; RAID 6 uses the equivalent of two. Example with 8 TB drives:

ConfigurationRaw capacityRAID 5RAID 6
4 bays × 8 TB32 TB24 TB16 TB
6 bays × 8 TB48 TB40 TB32 TB

RAID 6 survives the loss of two drives, a real advantage with large drives whose rebuild takes a long time: on a 6-bay unit it costs a third of the raw space, versus half on a 4-bay unit. The ceiling then depends on the drive sizes supported: TerraMaster quotes 132 TB raw for the F6-424 (six 22 TB drives). On the DS1621+, Synology caps a single volume at 108 TB. To choose the drives themselves, see our guide to hard drives for a NAS, and if you are still unsure about the number of bays, how many bays to choose.

RAID protects against a drive failure, not against a deletion, ransomware or the loss of the NAS itself: keep a copy of important data on another medium.

6-bay NAS units compared on paper

ModelProcessorRAM (shipped / max)Expansion
QNAP TS-673AAMD Ryzen V1500B, 4 cores / 8 threads, 2.2 GHz8 GB / 64 GB, ECC supported2 PCIe Gen3 x4 slots, 2 M.2 NVMe
Synology DS1621+AMD Ryzen V1500B, 4 cores4 GB ECC / 32 GB1 PCIe Gen3 slot (x4), 2 M.2 NVMe, 2 expansion ports
TerraMaster F6-424Intel N95, 4 cores, up to 3.4 GHz8 GB non-ECC DDR5 / 32 GB10 Gbit/s USB (Type-A and Type-C)

The QNAP TS-664 and the UGREEN DXP6800 Pro are covered further down, outside the table: we only recorded part of their specifications.

QNAP TS-673A: 64 GB of RAM and two PCIe slots

The TS-673A offers six 3.5-inch SATA bays (compatible with 2.5-inch drives and SSDs) and two M.2 2280 NVMe slots (PCIe Gen3 x1) for SSD caching or Qtier. Its 4-core, 8-thread Ryzen V1500B comes with 8 GB of DDR4 as a single module, expandable to 64 GB with two identical modules, with ECC support. The two PCIe Gen3 x4 slots take a 10 GbE card, extra M.2 SSDs or a card to connect JBOD enclosures. It has two 2.5 GbE ports and runs QTS or QuTS hero. Its spec sheet lists 21.9 W with drives sleeping and 45.9 W in typical operation with all bays populated, 20.3 dB(A), two 92 mm fans and a 3-year warranty extendable to 5 years. Worth knowing: the V1500B has no graphics, so HDMI output and a GPU require an optional PCIe card; to transcode video in Plex or Jellyfin, look at an Intel-based model instead.

Synology DS1621+: the 6-bay reference on DSM

Same Ryzen V1500B processor, but in the Synology ecosystem: six bays (3.5-inch SATA, 2.5-inch SATA drives or SSDs), 4 GB of DDR4 ECC across 2 slots, expandable to 32 GB, two M.2 2280 NVMe slots and one PCIe Gen3 slot (x4 link). It supports Synology Hybrid RAID, RAID 5, 6 and 10, on Btrfs or ext4, and has two ports for expansion units. You pick it for DSM and its backup and sync applications. As with any Synology NAS, check the drive compatibility list: Synology only guarantees full functionality with the models listed there. The Synology DS1621+ is the natural choice for anyone who already knows DSM.

QNAP TS-664: the 6-bay unit for video

The TS-664 lines up six SATA bays, two 2.5 GbE ports and a PCIe Gen3 x2 slot. Its spec sheet lists 4K H.264 hardware decoding, real-time transcoding and an HDMI 2.0 output at 4K 60 Hz: it is the model to consider for a Plex or Jellyfin library that needs transcoding, which the TS-673A cannot do without a card. It also supports virtualization and AES-NI encryption. The QNAP TS-664 therefore targets the family media library first. The processor and memory are not in the data we recorded: specialist reviews (NAS Compares) describe it with an Intel Celeron N5095, and the amount of memory should be checked on QNAP’s spec sheet if you plan to run virtual machines.

TerraMaster F6-424: 132 TB raw, no ECC

The F6-424 puts six bays (3.5-inch SATA, 2.5-inch drives or SSDs) behind a 4-core Intel N95, with 8 GB of non-ECC DDR5 in a single slot, expandable to 32 GB, two 2.5 GbE ports and two 10 Gbit/s USB ports. TerraMaster quotes up to 132 TB raw with 22 TB drives. Less memory and no ECC: it suits family storage or a media library rather than virtual machines. See the TerraMaster F6-424.

UGREEN NASync DXP6800 Pro: Core i5 and 10 GbE

The DXP6800 Pro is the 6-bay model in UGREEN’s NASync line, running the UGOS Pro system. According to our record of UGREEN’s product page (August 2026), it has a 10-core Intel Core i5 processor, 10 GbE networking and two Thunderbolt 4 ports: on paper, more cores and faster networking than the other models on this page; its memory and warranty are to be read on UGREEN’s page.

Neither 6 bays nor hard drives: two alternatives

Synology DS923+: start at 4, grow to 9. The DS923+ only has 4 SATA bays, but a 5-bay DX517 expansion unit connected to its eSATA port takes it to 9 drives. It relies on a 2-core AMD Ryzen R1600 (4 threads, up to 3.1 GHz), with 4 GB of DDR4 ECC expandable to 32 GB, two M.2 2280 NVMe slots and two 1 GbE ports (10 GbE optional with the E10G22-T1-Mini module). Worth considering if you start with four drives on a tight budget, as long as you accept the cost of the DX517 later. Synology replaced it in 2025 with the DS925+ (two 2.5 GbE ports, expansion over USB-C): check availability before buying. Other 4-bay units are compared in our pick of 4-bay NAS units.

Asustor Flashstor 6 FS6706T: six M.2 slots, no hard drives. The Flashstor 6 replaces drive bays with six M.2 2280 NVMe slots (PCIe 3.0 x1 each) and does not accept 3.5-inch drives internally. It uses a 4-core Intel Celeron N5105, 4 GB of DDR4 expandable to 16 GB, two 2.5 GbE ports, and its spec sheet lists 18.7 dB at idle. SSDs still cost more per terabyte than hard drives: it targets compact, quiet working storage, for example for video editing, rather than archiving large volumes. Asustor provides for up to two USB units (AS6004U or AS5004U, 4 bays each) to add hard drives.

Storing more without replacing the NAS

Once the internal bays are full, there are two options: replace the drives with larger ones, one at a time, letting each rebuild finish, or add an expansion unit. Manufacturers go about it differently:

NASSupported expansion
Synology DS923+one DX517 (5 bays) over eSATA, 9 drives in total
Synology DS1621+two expansion ports for Synology units
QNAP TS-673Aup to two TL-D800S JBOD enclosures (8 bays) via a PCIe card, or two TR-004 (4 bays) over USB
Asustor Flashstor 6up to two AS6004U or AS5004U (4 bays) over USB

Drives and expansion units come on top of the enclosure price: before buying a 4-bay unit with an expansion in mind, compare against the price of a 6-bay unit bought from the start.

Noise, power draw and placement

Six spinning hard drives are audible and run warm: a 6-bay NAS belongs in an office, a utility room or a technical closet rather than a bedroom. Power draw depends mostly on the drives and their standby settings, as the TS-673A’s two figures show (21.9 W with drives sleeping, 45.9 W in typical operation). The TS-673A and the DS1621+ are rated for a room between 0 and 40 °C according to their spec sheets. On the TS-673A, M.2 SSDs are not hot-swappable and QNAP recommends fitting them with a heatsink. For backups, the simplest solution is still an external drive plugged into the NAS: see backing up your NAS to an external drive.

Key facts

6 bays, 8 GB expandable to 64 GB
QNAP TS-673A (spec sheet)
6 bays, 4 GB ECC expandable to 32 GB
Synology DS1621+ (spec sheet)
132 TB raw (6 × 22 TB)
TerraMaster F6-424 (spec sheet)
21.9 W drives sleeping, 45.9 W typical
TS-673A power draw (spec sheet)
